The Fusion – USA FB254T5MVE 54W 2L T5 Electronic Fluorescent Ballast stands out with its high efficiency and reliability, designed to support 1-2 T5 lamps and equipped with a robust 120-277 VAC voltage rating. With a power factor and ballast factor of 0.99, it ensures minimal energy loss while maximizing performance. Ideal for commercial lighting applications, this non-dimmable, thermally protected ballast features a programmed start to extend lamp life and reduce energy consumption, complemented by a comprehensive 5-year warranty and multiple safety certifications. Perfect for both new installations and upgrades, it offers a smart solution for energy-conscious lighting needs.
Ballast Factor | 0.99 |
---|---|
Dimmable | Non-Dimmable |
Frequency Rating | 60 Hertz |
Lamp Type | T5 |
Minimum Starting Temperature | -20˚F / -29˚C |
Mounting | Fixture |
Number Of Lamps | 1-2 |
Power Factor | 0.99 |
Standard | cULus RoHS FCC ANSI CODE C82.11 C62.41 |
Start Type | Programmed |
Thermal Protection | Thermally Protected |
Title TUS Web | 54W Electronic Ballast, Non-Dimmable, 120-277V |
Type | Fluorescent Ballast |
Voltage Rating | 120-277 VAC |
Wattage | 116 Watts |
Weight | 1.6 Pounds |
Dimensions | L: 9.5 in W: 1.72 in H: 1.18 in |
Box Quantity | -- |
Carton Quantity | -- |
